Drilling System V630
3 separate servo controlled drilling units
Simultaneous drill profiles vertically or horizontally
CNC controlled
Can be equipped with feeder rolls or feeder truck
Designed for big size fabricators
Operating range: 10 – 600 mm / 60 – 1.250 mm
CNC Cutting Corridor VB1050
Cnc machine automatic cutting-piercing beams Voortman house, Max 1050 mm x 15000 mm. With simultaneous rotation 15 carbide drill and because it can works simultaneously cutting and drilling can produce 1500 tons per months.
Plate punching & Drilling System V250
V250 Plate punching machine (executed with a VPC 1000 Hydraulic 3-tool punching unit with manual quick-change adapters and an X-Y coordinate table). Drill Changer (6 positions). Carbide tipped drill for highest quality and faster process.
Punching & shearing System V550
Infeed system, suitable for flat steel and angle steel with a length up to 9m and provided with a feeder truck with material clamping.
Infeed drag-chain cross transports, 5 driven supports.
Vertical punching machine, punching capacity 100 ton. The punching machine is fitted with 3 punches.
Shear for flat steel, shearing capacity 180 ton.
Shear for angle steel, shearing capacity 180 ton.
Robotic Machine V808, by Voortman
Robotic thermal cutting machine equipped with the new faster and more accurate versatile Panasonic TL 1800G3 coping robot, dimensions: 5720x4460x3600 and weight: 11tns.
Custom Cross- Section Beam Operator
Custom cross-section beam operation (drawn- ark) machine max operation range 3300 x 1250 x 25000 m.
Cutting machine type: Volcano CNC-CG-5000
Cutting thickness: 5-150 mm
Rail Length: 30000 mm
Effective cutting width: 4200mm
Effective cutting length: 27000mm
Cutting speed: 1-6000mm/min
CNC Cutting Machine ESAB
CNC cutting machine ESAB for plates up to 200 mm ( cutting 3m x 15m with 4 oxygen and 1 plasma).
HACO Hydraulic Guillotine Shear
HACO Shear 12mm x 3000 mm
HACO - ADIRA Hydraulic Press Break
800 t Press Break with useful load 6000 mm Adira House.
220 t Press Break with useful load 3600 mm HACO House.
NEW PLATE BENDING MACHINE - DAVI MAV Z42
DAVI FULL HYDRAULIC PLATE ROLLING – Digital, SERVO-TRONIC Synchronized, Full Hydraulic, Press Roll – Variable Axis DAVI “MAV Z42” (4200 mm x 202 mm) , Max Bending power 3500 tons.
DAVI MCB 3090
Rolling of plates up to 3000mm width and 155mm thickness which is situated by Four (4) SERVO-TRONIC Synchronized, CNC MCB 3090 Full Hydraulic Rolls
Bevel Machine
Bevel machine with 4 heads up to 200 mm, 30m lenght ± 60° degrees
Bevel machine
Bevel machine up to 100mm ± 60° and armox plates
Automatic Submerged Arc Welding Machines
16 Pieces AC/DC 1000SD Advanced Submerged Arc Welder Tandem Wire
Automatic Submerged Arc Welding Machine
Welding of plates and tubes despite of the quality of the material (it can weld plates/tubes) without any limitation in thickness.The machine (electrical moving and electrical rotation) is moving on rails in order to facilitate it’s length capacity and on axes (height: max 5 m – width: max 5m)The welding can be performed with single or twin wire.
SELF ALIGNING TURNING ROLLS - STANDARD
CAPACITY : 60TN 12 SETS- 100TN 8 SETS – 150TN 4 SETS – 200TN 15 SETS
SELF ALIGNING TURNING ROLLS - FIT UP
CAPACITY : 60TN 4 SETS- 100TN 4 SETS- 150TN 4 SETS – 200TN 4 SETS
Straddle Carrier, by Combilift
Remote Control Telescopic Straddle Carrier SC1260C, by Combilift, that can handle steel structures up to 70tns.
Straddle Carrier, by Lykomitros Steel
Remote Control Telescopic Straddle Carrier LS1 by Lykomitros Steel, that can handle steel structures up to 300tns.
Boring Machine
Boring VEB UNION GERA, “FRITZ HECKERT” GBFKF150/1 Tischbohrwerk
CNC BORING MACHINE
Boring cnc machine with heidenhain controller TNC320. Dimensions 10000mm x 3400mm x 2000mm.
Vertical Lathe Machine
6m diameter – 4m vertical
Vertical and Horizontal Lathe Machine
2 meter diameter
Face Plate Lathe Machine
2200mm diameter – 3000mm length
Lathe Machine
800mm diameter 3000mm length
CNC MACHINING CENTER DAEWOO MYNX 500
Fanuc 21M CNC Control , 24 Tools Tool Changer , High precision 8000 RPM Spindle ,Manual Pulse Generator , Spindle Orientation ,Rigid Tapping , Fast Rapid Traverse Rate
CNC LATHE MACHINE
HEIDENHAIN 620 PLUS CONTROL , DIMENSION ( 6000mm )
COMBILIFT Multi-directional forklift
5-10-15-25 tns lift capacity
LTMG FORKLIFT FD40
40 tns lift capacity
Full Automatic Closed Shotblasting Machine
18 turbines for shotblasting of complex steel structures with dimensions of 4.00 x 4.00 m (height x width) up to 50 tns weight
Automatic Sand Blasting Machine
Automatic sand blasting machine (pre- heating sand blasting- painting system) 2.50 m width.
Closed Painting Section Hall 1
Closed Painting Section 2100 m2 With Heating System
Closed Painting Area Hall 2
Closed Painting Section 3900 m2
